Last year, AMD launched the Ryzen 7 5800X3D with a massive increased L3 cache, tripling the 32MB on the  Ryzen 7 5800X with 96MB of L3 cache.

This launch was largely geared towards gamers as the increased L3 cache is useful for the complex, heavy-dataset nature of video games.

Following the success of that chip, AMD has not only launched its successor but expanded the range with an additional two CPUs with the multi-CCD Ryzen 9 chips.

What is AMD 3D V-Cache

The basics of AMD 3D V-Cache are largely self-explanatory from its name. AMD use a 3D stacking technology to stack a 64MB L3 cache die on top of their existing charge-coupled device (CCD). And a CCD is basically one CPU chiplet.

The existing CCD for each chipset is 32MB, and this then takes the L3 cache to 96 MB.

Ryzen 9 7900X3D & 7950X3D use different L3 cache per CCD

Interestingly, the Ryzen 9 7950X3D and Ryzen 9 7900X3D both have 128MB of L3 cache. That might look normal, considering it is double the cache of the non-3D CPUs, but we would have normally expected 192MB of L3 cache in total.

These two CPUs have two CCDs, and AMD has only applied the 3D V-Cache to one. One of the CCDs will have 96 MB, while the other will remain at 32MB.

This may look like they have cheeped out, and to some extent, they have, it is an expensive technology to implement, and that cost will be passed onto the customer.

However, there are benefits to this design too. Not all applications need such a large L3 cache, and more cache can introduce increased latency. Having one CCD with 32MB cache will allow them to clock higher for pure throughput workloads that wouldn’t benefit from the extra cache.

The 96 MB equipped CCD can then be used for things like gaming which will benefit from the L3 cache. The previous 5800X3D saw roughly a 15% improvement vs its vanilla Ryzen counterpart. We will hopefully see the same again with these new Ryzen 7000X3D chips.

AMD Ryzen 9 7950X3D vs 7950X and Ryzen 7 7800X3D vs 7700X vs 5800X3D Specs & Price

AMD Ryzen 7000X/X3D Series
Cores ThreadsBase FreqTurbo FreqL3 CacheTDPPrice
Release Date
Ryzen 9 7950X3D16C / 32T4.2 GHz5.7 GHz128 MB120W$69902/28/23
Ryzen 9 7950X16C / 32T4.5 GHz5.7 GHz64 MB170WRRP: US$699 / €849
Current: $529

Ryzen 9 7900X3D12C / 24T4.4 GHz5.6 GHz128 MB120W$59902/28/23
Ryzen 9 7900X12C / 24T4.7 GHz5.6 GHz64 MB170WRRP US$549 / €669
Current: $419

Ryzen 7 7800X3D8C / 16T4.2 GHz5.0 GHz96 MB120W$44904/06/23
Ryzen 7 7700X8C / 16T4.5 GHz5.4 GHz32 MB105WRRP: US$399 / €479
Current: $344
Ryzen 7 5800X3D8C / 16T3.4 GHz4.5 GHz96 MB105WRRP: $449/£429
Current: $336

Motherboard Support

AMD’s new Ryzen 7000X3D processors will be supported on all of AMD’s AM5 series motherboards, though many motherboards will require a BIOS update to properly utilise AMD’s Zen 4 X3D silicon. Thankfully, all AM5 motherboards can have their BIOS updates without an installed processor, making BIOS updating a non-issue.
